Heat transfer vinyl with self-adhesive polyester backing.

THICKNESS +/- 5%

Printable film: 110 microns

Polyester carrier: 120 microns

1. Print text, image, photo in normal positive mode.

2. Use the manual feed (manual feed) of the printer in the Heavy Mode setting.

3. If desired, cut out the contours using a plotter with an optical eye function

4. Adjust the blade to cut only the printing film, not the polyester carrier, then the weeds.

5. Place the mass on the textile so that the image is visible and protect the tape with baking paper.

6. Hot pressing at 140°C / 15 seconds on an automatic press with a pressure of 5 bar (70 PSI) or max.
hand press pressure.

7. Peel off the baking paper and application tape after cooling.

Pressure: 5 bar (70 PSI) on automatic press, maximum pressure on manual press.

Washing temperature: 40°C

ADVANTAGES

FABRIC: Cotton - Polyester - Polycotton - Nylon (try before use).

1. Very fast and economical printing on a standard CMYK laser printer (no need for a laser with white toner)

2. Professional soft touch, simple to transfer with a single format to use

3. High quality full color printing without rasterization/RIP software - Colors remain vivid even when pressed

4. Low temperature transfer at 140°C-15s (150°C-20s for nylon and 120°C-5s for sublimated polyester fabrics)

5. Fast weeding and easy to get small details

6. The possibility of cutting contours thanks to the plotter with the optical eye function

7. Universal thermo-adhesive with excellent proven adhesion to most textiles

8. Can be used without application tape for simple shapes

9. Elastic and strong film, withstands many washing cycles up to 40°C

10. Ecological water-based polyurethane, without solvents and PVC.

11. Production of low carbon profiles: all operations under one roof

12. 100% made in France, from European raw materials.

13. Latest generation machines and exclusive production process

RECOMMENDATION

1. Wait 24 hours before washing.

2. Do not use bleach or other aggressive chemicals.

3. Iron from the inside.

4. Store our products in a temperate and dry room, protected from direct sunlight.

SAFETY

Inert components, REACH compliant, free of PVC, plasticizers, heavy metals, VOCs, acc

according to Oekotex Standard 100 class 1.

RESUBLIMATION

You can transfer sublimated printed polyester at 120°C-5/10s - wash at 30°C
Apply UNITAPE 501 application tape after printing, cutting (positive mode) and weeding

IRON APPLICATION

( A4 SHEETS ) or 502 ( with insert ) to transfer the image to the garment. Protect the tape with pastry
paper, set the iron. Do not use any steam. Press hard, from
center towards the edges. Peel off the tape when cold.

Format: A4

Box: 100 sheets
